Product Description

We make automation & inspection systems for the printing and packaging industry.

We have developed a camera viewing system that does the following :-

• Compact magnifying camera for register mark view on each station
• Live display of register mark of each repeat from each station on a 32” widescreen monitor
• No teaching or difficult process needed so any operator can operate easily
• Combined split view image of register marks from all stations, LIVE (each repeat)
• Machine motor controls from same display
• Operator can watch the display & set register of each station at the same time, instead of waiting at the end of the machine to check the register mark manually. This reduces paper wastage, ink wastage & reduces time needed to set up a job. This also improves accuracy as the small 3mm register mark is magnified to a size of 100mm.

https://youtu.be/6nNefAIfgQo

https://youtu.be/txANbfBbUAw

This is a very economical solution that costs less than a single camera at the end of the machine. Let us know if interested.
